The corrosion resistance of SUS304 makes it ideal for conveyor belt tensioning devices on food processing lines, as it withstands frequent high-pressure water washdowns and disinfectant spraying. Its large-diameter flange provides robust axial support.
Bearing Features
In the gearboxes of manual or small power tools, it effectively secures the bearing position, preventing displacement caused by intense vibration. Even in industrial environments exposed to salt spray, the SUS304 surface maintains a stable passivation layer, ensuring excellent performance for the R1038 in applications involving precision instruments within ship compartments.
Technical Specifications
| Bearing Reference | Boundary Diameters | Basic Dynamic | Basic Static | Limiting Speeds | ||||||||||||||||||
| Flange | Open | Shield | d inch |
d mm |
D inch |
D mm |
Df inch |
Df mm |
B inch |
B mm |
Bf inch |
Bf mm |
B1 inch |
B1 mm |
Bf1 inch |
Bf1 mm |
rsmin inch |
rsmin mm |
Cr kN |
Cor kN |
Grease | Oil |
| F | SFR6 | ZZ | 0.375 | 9.525 | 0.875 | 22.225 | 0.969 | 24.613 | 0.2188 | 5.556 | 0.062 | 1.575 | 0.2812 | 7.144 | 0.062 | 1.575 | 0.0157 | 0.4 | 3.33 | 1.42 | 2.1 | 2.3 |
| - | SFR1038 | ZZ | 0.375 | 9.525 | 0.625 | 15.875 | - | - | - | - | - | - | 0.1562 | 3.969 | - | - | 0.0059 | 0.15 | 0.853 | 0.431 | 2.6 | 2.9 |
