The 69 series features an ultra-thin-walled design engineered for extreme weight reduction and space efficiency. The use of SUS420 stainless steel ensures the necessary radial rigidity despite the exceptionally thin outer ring walls. Manufacturing these bearings is highly challenging, requiring precision grinding processes to guarantee the roundness and consistency of both the inner and outer rings.
Bearing Features
From the perspectives of both aesthetics and functionality, the 69 series is ideally suited for applications such as handheld power tools, high-end drone motors, and various compact sensors. Its low-friction characteristics enable equipment to achieve very high rotational speeds with minimal energy consumption. Furthermore, the corrosion resistance of the stainless steel prevents rust caused by condensation—even in environments with significant temperature fluctuations—thereby ensuring smooth, quiet, and reliable long-term operation.
Technical Specifications
| Bearing Reference | Boundary Diameters | Basic Dynamic | Basic Static | Limiting Speeds | ||||||||||
| Flange | Open | Shield | d mm |
D mm |
Df mm |
B mm |
Bf mm |
B1 mm |
Bf1 mm |
rsmin mm |
Cr(kN) | Cor(kN) | Grease | Oil |
| F | S691 | - | 1 | 4 | 5 | 1.6 | 0.5 | - | - | 0.1 | 0.137 | 0.039 | 13.2 | 14.8 |
| F | S692 | ZZ | 2 | 6 | 7.5 | 2.3 | 0.6 | 3 | 0.8 | 0.15 | 0.333 | 0.098 | 8.3 | 9.3 |
| F | S693 | ZZ | 3 | 8 | 9.5 | 3 | 0.7 | 4 | 0.9 | 0.15 | 0.559 | 0.176 | 6 | 6.7 |
| F | S694 | ZZ | 4 | 11 | 12.5 | 4 | 1 | 4 | 1 | 0.15 | 0.96 | 0.353 | 4.4 | 4.9 |
| F | S695 | ZZ | 5 | 13 | 15 | 4 | 1 | 4 | 1 | 0.2 | 1.08 | 0.431 | 3.7 | 4.1 |
| F | S696 | ZZ | 6 | 15 | 17 | 5 | 1.2 | 5 | 1.2 | 0.2 | 1.34 | 0.519 | 3.1 | 3.5 |
| F | S697 | ZZ | 7 | 17 | 19 | 5 | 1.2 | 5 | 1.2 | 0.3 | 1.61 | 0.715 | 2.8 | 3.1 |
| F | S698 | ZZ | 8 | 19 | 22 | 6 | 1.5 | 6 | 1.5 | 0.3 | 2.23 | 0.921 | 2.4 | 2.7 |
| F | S699 | ZZ | 9 | 20 | 23 | 6 | 1.5 | 6 | 1.5 | 0.3 | 2.47 | 1.08 | 2.3 | 2.6 |
